Constant, reproducible clamping force with mechanical force amplifierMechanical stop for safe operation, max. clamping force 60 kNProven maintenance-free and encapsulated high-pressure spindleBasic body made of GJS-60Guideway inductively hardened and groundAligning grooves in the base faceEvenness of basic body 0.01mmReversible jaws: for min. / max. clamping range (0-245 mm, 190-435 mm) with one pair of jawClosing and opening of the complete clamping range including clamping process with a hand crankDimensions NC4 as for NC8, LC and TC 160, thus placing them side by side possibleJaw interface compatible with NC8 and LC/TC2 thread per side for lateral workpiece stops M8Individual QR code for fast access to technical information
