Product features:
• Monitoring of the clamping force during clamping and machining due to integrated, electronic measuring system.
Readout directly on display and via wireless transmission to terminal device (via Bluetooth BLE)
• Encapsulated spindle with force amplifier (IP65). Input of max. 30 Nm for 40 kN clamping force
• Operation via torque wrench
• All jaws of the Titan2/NC8 series can be used
• Jaws reversible
• Unmachined parts in highly varied materials or with complex geometries, can be clamped securely.
Different gripp-studs for materials up to approx. 1400 N/mm² strength
• Quick change for attachment jaws and parallels
• Titan2 spindle can also be used without monitoring
• Holes for workpiece stop, angular drive and extension
• Sides are ground
• Bottom side with alignment grooves and locating holes Ø 25H6 M10 for zero-point clamping systems, inside micometre 200 mm ± 0,01 mm
- Simple use of the clamping force monitoring:
• Clamping force can be recorded with all compatible jaws, as the measuring unit is in the spindle
• Transmission range up to 20 m
• Long battery life
• Easy & quick battery change with standard batteries
• Display robust and splash-proof
• Operating temperature between 10° C and 40° C
• Individual QR code for fast access to technical information, accessories, spare parts and service
